SR5 Panel Saw / Router

$5,257.00

The SR5 can be changed from a saw to a router in 30 seconds while delivering an accuracy of 1/64” straight and square. The patented self-adjusting router carriage provides a consistent depth of cut. For shops with limited space, this versatile machine is ideal where both panel sizing and panel routing are required. Ask about our V-grooving package.

Standard Equipment

  • 3 ¼ Hp, 15 amp saw motor.
  • 1 ¾ Hp, 11 amp router motor.
  • 10 ft. welded steel frame.
  • Chrome-plated 1 ¾” guide tubes.
  • 8 Nylatron roller bearing system.
  • Adjustable vertical and horizontal rulers.
  • Quick change from vertical to horizontal cutting.
  • Enclosed counterweight system.
  • Integrated dust collection bonnet.
  • Thin material pressure guard.
  • Injection molded plastic
  • Adjustable floating router head.
  • MID-WAY FENCE™ with stop.
  • MID-WAY FENCE™ flip stop.
  • 4 material clamps.
  • 2 blind dado stops.
  • Extended warranty.
  • TUV certified to UL/CSA standards.

Technical Data

Max. Crosscut 62"/1575mm
Max. Rip Cut Unlimited
Max. Cut Thickness 1 3/4"/45mm
Cut Accuracy, Straight and Square 1/64"/.4mm
Saw Blade Diameter 8"/210mm
Motor 15 amp, 120V, 220V
Router Motor 11 amp, 120V, 220V
Frame Length 120"/3050mm
Product shipping information
Weight 538 lbs
Dimensions 120 × 11 × 83 in
