The CMS Helix 75L is a single-blade automatic beam saw designed for cutting plastic, acrylic, and synthetic panels. It represents an entry-level / small-company solution, offering essential cutting capabilities in a compact, flexible package. Its PC/PLC-based control and straightforward structure make it ideal as a standalone saw or as part of a larger production line handling plastic sheet processing.
-
Excellent price-to-performance ratio — A cost-effective solution for smaller operations or as an auxiliary saw, providing reliable performance without unnecessary complexity.
-
Flexibility for diverse needs — Capable of handling various panel sizes and easily integrable with automatic horizontal sheet magazine systems, offering scalability and ease of automation.
-
Simple, compact design — The straightforward structure keeps maintenance and operation easy, and the modest footprint fits smaller workshops.
| Parameter | Specification |
|---|---|
| Cutting dimensions (panels) | 3300 × 2100 — 4300 × 4300 mm (various configurations) |
| Blade projection | 80 mm |
| Main blade / engraver blade diameter | 340 / 200 mm |
| Max blade carriage speed | 60 m/min (optional 120 m/min) |
| Max plunger speed | 60 m/min (optional 70 m/min) |
| Blade motor power (with inverter) | 7 kW (standard), optionally 9 or 11 kW |
| Engraver motor power | 1.5 kW |
| Blade rotation speed (c/inverter) | 1,000 – 5,000 rpm |
| Number of single-claw collets (standard) | 5 |
