- Hook up one to three machines for optimum dust cleaning
- Quick-install collection bag makes emptying and re-attaching a snap
- Single-stage design for economical and quiet operation
- Includes four casters for maneuverability and total portability
- High air velocity (CFM) design stands up to any competitive specifications
- Permanently lubricated, totally enclosed, fan-cooled motors are rated for continuous-duty
| Height | 18.000 |
| Length | 32.000 |
| Gross Weight | 91.000 |
| Net Weight | 86.000 |
| Volume | 5.167 |
| Width | 15.500 |
| Ready For Web (US) | Yes |
| Prop 65 | Cancer and Reproductive Harm |
| Style (Type) | Bag |
| Prewired Voltage (V.) | 115 |
| Motor Power (HP) | 1 |
| 1-Hose Connection Diameter (In.) | 4 |
| Collection Bag Length (In.) | 21-1/2 |
| Filter Efficiency (Micron) | |
| Filter Bag/Canister Length (In.) | 31-1/2 |
| Impeller Diameter (In.) | |
| Motor Voltage (V.) | 115/230 |
| 3-Hoses Connection Diameter (In.) | |
| Recommended Circuit Size (Amps.) | |
| Impeller Fins | |
| Motor Phase (PH) | 1 |
| Collection Bag Capacity (Cu. Ft.) | 2-1/10 |
| Impeller Material | Steel |
| Number of Air Inlets | |
| Wiring Remarks | |
| Sound Rating (Db.) | 65 - 70 |
| Bag Diameter (In.) | 14 |
| 2-Hoses Connection Diameter (In.) | |
| Motor Amps | 11/5.5 |
| Collection Drum Capacity (gal.) | |
| Max. Static Pressure (Wc.) | |
| Drum Collection Bag (Dia. x L/In.) | |
| Canister Collection Bag (Dia. x L/In.) | |
| Canister Filter Diameter (In.) | |
| Canister Filter Length (In.) | |
| Assembled Dimensions (L x W x H/In.) | |
| Footprint (L x W/In.) | |
| Motor Speed (RPM) | |
| Efficiency (Micron) | |
| MERV Value | |
| Air Flow (US Method) @ 4 (CFM) | |
| Air Flow (US Method) @ 6 (CFM) | |
| Air Flow (US Method) @ 8 (CFM) | |
| Air Flow (EU Method) @ 4 (CFM) | |
| Air Flow (EU Method) @ 6 (CFM) | |
| Air Flow (EU Method) @ 8 (CFM) | |
| Air Velocity (US Method) @ 4 (FPM) | |
| Air Velocity (US Method) @ 6 (FPM) | |
| Air Velocity (US Method) @ 8 (FPM) | |
| Air Velocity (EU Method) @ 4 (FPM) |
