SCM Olimpic 500P HP Edgebander

by SCM

$135,000.00

Payment Calculator

Financing Request

SKU WSI-SCMK500PHP

Model

Quantity

SCM Olimpic 500P HP / AF

Automatic edge bander designed to process panels for different applications with excellent productivity and quality performance.

Ideal for medium-sized companies, it is a highly versatile solution thanks to the possibility of using different types of gluing: EVA, PUR glues and hot air technology.

Features (model replacement of K560HP and K560HP AF)

NEW EYE-M-EVO Controller
24” High Resolution Touch Screen
Unlimited Number of Working Programs
Provides Diagnostic, Maintenance and Production Information
LED Light Bar to Indicate Machine Status
Windows 10 Operating System
Available in 5 languages
NEW Two Motor Pre Mill Unit (2.0hp)
100mm Diamond Cutters With Replaceable Inserts
Maximum thickness removal of 3mm/Maximum stock removal of 80mm2
Mechanical Digital Readout for Stock Removal
Pneumatic Positioning Through Controller
Fence Moves on THK Guides
NEW Servo Driven Pressure Section
SGP Glue Pot
4 Roller Pneumatic Pressure Section
Jump Pressure Section
Maintenance Free Bearing on Glue Pot
I-Glue, Pneumatic Locking of Glue Roller on Trailing Edge
1.5kg glue pot capacity

Air Fusion+

AF15 AirFusion+ Unit – 50fpm
50% Quicker Heat Up Time
Requires Half the Air Pressure of the
Quicker Cool Down, roughly 5 minute
Silencer Mounted Above the Unit
Min/Max Edge Thickness 1mm/3

Duty Cycle:

5-6 Hours of Production Per Day

Capacities / Feed Speeds / Panel Thickness:

8mm / 40-60 fpm / 60mm

VERSATILITY

A perfect glue line for high quality panels is possible thanks to the SGP glue pot that allows the use of the EVA and PUR glue with simple and quick changeovers.

Processing of narrow panels up to 60 mm wide and gluing of solid wood edges up to 12 mm thick.

Technical data

Technical data olimpic 500plus
Edge thickness	mm	0,3 - 8 (12)
Panel thickness	mm	8 - 60
Minimum panel width	mm	60
Feed speed	m/min	12 -18
Compressed air	bar	6
