- With 2′ digital readout control panel
- Hydraulic blade tension
- Saw wheel elevation is driven by motor
- Conveyor is driven by hydraulic motor
| Max. board/cant size | 11.8″ (W) x 9.8″ (T) (300 x 250mm) |
| Distance from upper blade to conveyor table | .79″ – 6.7″ (20 – 170mm) |
| Distance from lower blade to conveyor table | .47″ – 4.9″ (12 – 125mm) |
| Conveyor belt size | 11.2″ x 215.7″ (285 x 5480mm) |
| Diameter of saw wheel | 28″ x 1″ wide |
| Variable feed speed | 0 – 68 FPM (0 – 20 M/min.) |
| Saw blade size | 168″ x 1″ x 2 pcs. |
| Motor | 20 HP x 2 pcs. |
| Gear box motor | 1/4 HP x 2 pcs. |
| Dust hood | 4″ x 2 pcs. |
