GKS G10 Ton, Forklift Jack

by GKS
SKU GK1-12378

G10, Forklift Jack

The G10 Forklift Toe Jack is an ideal tool for factories and manufacturing facilities, whether they require equipment for lifting industrial vehicles, hauling, rigging or other applications. Regardless of indoor or outdoor use, the self-contained, easy-to-use G10 can expertly handle up to a 10 ton load capacity (22,000lbs.)

Designed with safety, strength and stability in mind, the G10 forklift toe jack features three lift-toe positions which allow operators to easily and safely lift heavy loads, plus a safety valve that protects operators from overloading the jack. The G10 arrives ready to use and features extra-long, base-integrated feet; an extended reinforced safety toe with grooved surface for maximum stability, and a release valve for precise and sensitive lowering.

Product Info Sheet


  • Specially designed for maintenance purposes on forklifts and other industrial vehicles
  • Outstanding stability due to solid feet and an extended grooved safety toe
  • 3 starting positions


  • Weight: 126 lbs.
  • Load Capacity: 22,000 lbs (10 t) 100 kN
  • Working Pressure: 7,542 psi (520 bar)
  • Loading Height: Toe min 1.2" (30 mm)
  • Lifting Height: 5.5" (140 mm)
  • Lift Toe Positions: 3
  • Top Plate (L x W): 2.7 x 2.4" (68 x 60 mm)
  • Loading Height: Top plate 12.5" (318 mm)
  • Dimensions (L x W x H): 18.1 x 11 x 12.5" (461 x 280 x 318 mm)
  • Weight with oil: 127 lbs. (57 kg)
