- Heavy duty die-cast aluminum and steel body provides rigidity for consistent quality
- Patented dust hood incorporates an integrated channel that directs dust to a 4 collection port.
- Parallelism adjust dial features a stop to quickly return the conveyor bed to a flat position
- Infinitely variable-speed control allows the user to choose the optimal feed rate
- Open ended design allows for up to 20 of sanding capacity with 2 passes
- Extruded aluminum drum is designed to dissipate heat and protect wood from heat-damage
- Redesigned conveyor system pulls the workpiece through the sander instead of pushing
- Toolless abrasive take-up fasteners make changing abrasives quick and easy
- Precision-flattened reinforced steel conveyor bed supports the boards passing under the sanding drum
- Control system with integrated circuit breaker protects motor from over heating
| Height | 0.000 |
| Length | 0.000 |
| Gross Weight | 82.000 |
| Net Weight | 73.000 |
| Volume | 5.988 |
| Width | 0.000 |
| Ready For Web (US) | Yes |
| Prop 65 | Cancer and Reproductive Harm |
| Wiring Remarks | |
| Electrical Controls | |
| Recommended Circuit Size (Amps.) | |
| Drum Length (In.) | 10 |
| Minimum Board Thickness (In.) | 1/32 |
| Dust Collection Minimum CFM Required (CFM) | 550 |
| Minimum Board Length (In.) | 2-1/4 |
| Maximum Board Width (In.) | 20 |
| Drum Diameter (In.) | 5 |
| Prewired Voltage (V) | 115 |
| Maximum Board Thickness (In.) | 3 |
| Motor Amps | |
| Motor Phase (PH) | 1 |
| Motor Power (HP) | 1 |
| Number of Sanding Drums | 1 |
| Dust Port Outside Diameter (In.) | 4 |
| Conveyor Motor | Totally Enclosed DC |
| Conveyor Speed (FPM) | 0 to 10 |
| Motor Voltage (V) | 115 |
| Style (Type) | SV_1375591258774 |
| Drum Speed (RPM) | 1725 |
| Drum Bearing Diameter (In.) | |
| Weight (Lbs.) | 73 |
