- Upper blade holder clamps and tensions blade in one step (Patent Pending)
- Removable lower blade holder attaches quickly and securely into place
- Large 11-5/8 x 21, 1/4 thick steel table provides a stable working surface while also limiting vibration
- Slotted table for easier and quicker blade changes
- 18 throat capacity
- Arm tilts 45 right and 30 left, keeping the work table flat for more accurate cutting
- Top lift, spring loaded arm raises 10 and stays up until pulled back down
- Removable dust port on underside of table to collect dust at the source
- Variable speed range of 400 – 1550 strokes per minute
| Height | 17.300 |
| Length | 30.700 |
| Gross Weight | 62.500 |
| Net Weight | 54.000 |
| Volume | 0.579 |
| Width | 15.700 |
| Ready For Web (US) | Yes |
| Prop 65 | Cancer and Reproductive Harm |
| Table Material | Steel |
| Stroke Length (In.) | 3/4 |
| Tilting Function | Arm |
| Blade Tilt Range (Deg.) | 45 Right/30 Left |
| Throat (In.) | 18-1/2 |
| Maximum Cutting Depth (In.) | 2 |
| Speed Range (Stroke/min) | 400 - 1550 |
| Table Size (L x W) (In.) | 11-5/8 x 21-1/4 |
| Motor Voltage (V) | 120 |
| Motor Amps | 1.3 |
| Table Height (In.) | 7-3/4 to 8-3/4 |
| Assembled Machine Dimensions (L x W x H) (In.) | 33 x 15-1/2 x 17-1/2 |
| Net Weight (Lbs.) | 54 |
| Dust Port Outside Diameter (In.) | 2-1/2 |
