The Nova SI 400 is SCM’s best-selling sliding table saw. This machine comes with a 350mm (14”) main blade (maximum blade capacity is 16”) and adjustable “EZ Dial” split scoring blade. It features a 10.5’ squaring stroke on an anodized aluminum sliding table with hardened steel guides and an impressive 11 horsepower 3-phase motor to cut through tough materials with great precision. Our customers appreciate the ease of use and production capabilities this saw has to offer.
3-phase, 10.5' sliding table with 11 horsepower and up to a 16" blade capacity with 1" arbor.
Blade Group Trunnion for Tilting
The double trunnion assembly for blade tilting is part of the blade group casting. The entire blade group raises and lowers on two dovetailed steel guideways. This casting eliminates the possibility of misalignment which exists when these parts are bolted in place or pivoted on a pin as some manufacturers do. Our engineered direct shaft drive coupled with rack and pinion allows for a smooth angle adjustment of the saw blade.
New Wider Sliding Table
The Nova SI 400 has a new, wider, sliding table with two channels for added versatility. This is a feature normally only found on our larger machines. The hardened steel guideways are machined into place (no glue), and are designed to last the life of the machine with no adjustments needed.
E-Z Dial Scoring Set
Adjusting the scoring set is quick and easy. Simply turn the dial to adjust the width of the score. This system eliminates the need for shims and the constant adjustment they require. It is fully adjustable in 0.1mm increments.
Overarm Saw Guard
The Nova SI 400 comes standard with an overhead blade guard. Whether you are cutting sheet goods, or 5” thick solid wood lumber, this guard has you covered. The guard also has a dust collection outlet to aid in the removal of dust and other airborne particles.
Heavy Rip Fence Support and Knuckle
The Nova SI 400 has a robust knuckle and rip fence that ride on a heavy-duty steel bar. A sturdy cam lock, micro adjustment handle and a completely adjustable high/low aluminum fence extrusion come standard with the machine.
Radius Steel Guideway System
Guideways are ground to tolerance allowing for a precise and permanent fitting of the wagon assembly. The radius is ground into the steel guides which increases the contact area along the bearing surface which eliminates pre-mature wearing of the bearing and guides. The steel guides are mechanically dovetailed (not glued) into place and have a +/- 0.05mm (.002”) tolerance along the entire length of the carriage. The carriage will never require adjustment due to its structure with arch-ground steel guideways (developed by SCM). All classical SCM sliders come with a 10 year warranty on table guideway tolerances.
Flip-Stops and Boom Extension
The Nova SI 400 has two flip-over stops for fast referencing when cutting workpieces with the same dimensions. This saw also has a crosscut fence that is over 90” long and a boom extension that can extend it another 48” when working with large panels.
Cast-Iron Blade Group
The Nova SI 400 has a massive cast-iron blade group which tilts on a trunnion mechanism. This closed system allows for maximum dust removal and is the most durable tilting design. The gear assemblies are encased which prevent dust or pitch to penetrate the joining mechanisms. Other inferior systems have an open structure which allows the blade group to twist when one of the trunnions is blocked by pitch or dust, thus throwing off your entire blade group and the accuracy of your cut.
- Anodized aluminum sliding table with hardened steel guides
- Automatic self-braking motor
- 11Hp main blade motor
- Separate 1Hp scoring motor
- Mechanical tilt indicator
- Tilting arbor from 0° to 45°
- Separate hand wheels on front for lifting and tilting of blade
- External scoring saw adjustment with stops
- Slider locks anywhere to the right of the blade
- Overhead mounted blade guard with dust outlet
- Heavy industrial aluminum extrusion crosscut fence with flip stops
- Standard 1 year warranty (10 years on table guideway tolerances)
- Eccentric Clamp
- Electrical control panel tilted 25° deg. for ergonomics
- Complimentary 350mm starter blade
- Complimentary ”EZ Dial” adjustable split scoring blade assembly
**Specifications are subject to change**
