Used 2019 MB Roba-T-13-03-DB Wide Belt Sander

Used 2019 MB Roba-T-13-03-DB Wide Belt Sander

by MB Roba
$115,000.00
Payment Calculator
Financing Request
SKU

Engineered for maximum sanding efficiency, the 2019 MB ROBA-T-13-03-DB is a high-performance, industrial-grade rotational brush sander designed for white wood and sealer/intermediate lacquer sanding. This machine replaces traditional, aggressive drum sanders with an innovative wide-area brush belt system, ensuring a flat, wave-free finish on solid wood, MDF, veneer, and lacquered parts.

Featuring a 360-degree rotating sanding aggregate, it is the premier choice for handling complex profiles, shaker doors, and profiled panels in furniture and joinery production.



Recently removed from service in good working condition.

9/10 condition, only exception is normal use markings.

FOB: San Antonio, TX

  • ROBA Tech Sanding Principle: Equipped with a wide-area sanding belt featuring approximately 174 sanding strips (1300 x 1500 mm contact area), offering over 250 meters of abrasive material.
  • 360° Rotation: The main sanding aggregate rotates 360 degrees, allowing it to reach all edges and corners of the workpiece consistently.
  • Dual Counter-Rotating Brushes: Includes counter-rotating brushes on the outfeed, ideal for panel cleaning or additional abrasive brushing.
  • Vacuum Transport System: Advanced vacuum bed ensures secure transport of small or lightweight workpieces.
  • PLC Touch Screen Controls: Programmable controls allowing for the storage of sanding parameters (3+ programs) and easy operator interface.
  • Wide Working Width: 1,300 mm (51”) working width enables high-volume production.
  • Year: 2019
  • Working Width: 1,300 mm (51.18”)
  • Working Height: 33.5” – 35.5” (adjustable)
  • Feed Speeds: Variable 3 - 12 MPM (9 - 36 FPM)
  • Sanding Speed: 30 -140 MPM (98 - 459 FPM)
  • Total Power Consumption: 14 KW / 40A
  • Voltage: 480Y/277V AC 60Hz 3Ph
  • Extraction Requirement: 4510 CFM
  • Dimensions: Approx 152” Length x 102” Width x 80” Height
  • Weight: ~8,400 lbs.
  • White Wood Sanding (solid wood, MDF, veneer)
  • Intermediate Lacquer/Sealer Sanding
  • Profiled Molding Sanding
  • Deburring (if configured for metal)
